Prices & Specifications
| The original and best one-person loading system for long bikes |
|---|
| Item Code | Maximum Wheelbase |
Minimum Load Bar Spacing |
Application | Wt Capacity (lbs) | Approximate Installed Wt (lbs) |
MSRP |
|---|---|---|---|---|---|---|
| TT-076 | 76" | 22" | Traditional tandems Recumbent tandems including the Rans Screamer * MOST POPULAR * |
50 | $725.00 | |
| TT-084 | 84" | 22" | Extra long tandems & recumbent tandems including the Rans Seavo |
50 | $760.00 | |
| TT-095 | 95" | 30" | Bicycles with wheelbases up to 95" | 75 | $1,015.00 | |
| TT-105 | 105" | 35" | Triplet tandems Carries a triple, double or single bicycle |
75 | $1,045.00 | |
| TT-other | really long | even wider | Super long models for just about every need including quad tandems |
varies | varies | varies |
THRU AXLE CONVERSION KITS
| Converts your classic 9x100 quick release TANDEM TOPPER to thru axle style Fits all Tandem Toppers and Thule 558p made since 2007 ( Not compatible with Bike Toppers ) |
|---|
| Item Code | Application | MSRP |
|---|---|---|
| TTCK-TA12100 | 12 mm diameter x 100 mm wide fork/hub spacing | $125.00 |
| TTCK-TA12110 | 12 mm diameter x 110 mm wide fork/hub spacing | $125.00 |
| TTCK-TA15100 | 15 mm diameter x 100 mm wide fork/hub spacing | $125.00 |
| TTCK-TA15110 | 15 mm diameter x 110 mm wide fork/hub spacing * Most common * |
$125.00 |
| Non-pivoting racks for tandems, recumbents, and singles |
|---|
| Item Code | Maximum Wheelbase | Minimum Load Bar Spacing |
Application | Wt Capacity (lbs) | Approximate Installed Wt (lbs) |
MSRP |
|---|---|---|---|---|---|---|
| BT-45 | 45" | 12" | Traditional single bikes Ideal for cars with short roof lines |
50 | $240.00 | |
| BT-HT51 | 51" | 20" | HIGH TOPPER high rise fork mount + wheel tray for singles with low fenders, pannier racks, etc. |
50 | $245.00 | |
| BT-63 | 63" | 15" | Cargo bikes, cruisers,crank forwards, & other bikes that need a longer tray |
50 | $325.00 | |
| BT-76 | 76" | 22" | Tandems & recumbent tandems | 50 | $515.00 | |
| BT-84 | 84" | 22" | Extra long tandems & recumbent tandems | 50 | $550.00 | |
| BT-EGO | 57" | 15" | Specially designed for the ElliptiGO Fits all ElliptiGO models |
50 | $345.00 |
Topper Mounting Hardware
The mounting hardware included with each Topper Rack fits
Thule (rectangular) and Yakima (round) compatible load bars.
Mounting kits are available for T-slot style load bars. (see below)
Mounting hardware included with each Topper Rack fits
Thule (rectangular) and Yakima (round) compatible load bars.
Mounting kits are available for T-slot style load bars. (see below)
| T-Slot Load Bar Mounting Kits for all Topper Racks and Thule 558p |
|---|
| Item Code | Application | MSRP |
|---|---|---|
| MK-2025-Tpr | Mounting kit to put a Topper on load bars with a T-slot in the top Fits: Thule WingBar, ProBar, AeroBlade, Rapid Aero Yakima Jetstream, Whispbar Rhino Vortex OEM (factory) load bars from VW, Audi, Mercedes, BMW, Mini Mazda CX90 OEM load bar Menabo Delta |
$69.50 |
| MK-2025-Tpr-OE | Same as MK-2025-Tpr but supplied as an Original Equipment factory substitution for standard mounting kit |
$34.75 |
| MK-2025-07 | Our TESLA kit corrects for arch of the Tesla load bars so your bike sits upright Tesla Model S, Model Y |
$125.00 |
| MK-2025-07-OE | Same as MK-2025-07 but supplied as an Original Equipment factory substitution for standard mounting kit |
$85.00 |
SECURITY SKEWERS
| Item Code | Description | Approximate Installed Wt (lbs) |
MSRP | Notes |
|---|---|---|---|---|
| TL | Topper Lok™ security skewer Lockable, long-throw cam, rust proof Fits all 9mm fork mounts with a removable skewer Uses an ordinary padlock or ML605 below |
$79.00 | ||
| TL-OE | Upgrade any Draftmaster or Topper Rack to a Topper Lok™ Original Equipment factory substitution for standard skewer |
$73.00 | ||
| ML605 | This hard-to-find padlock works great with our Topper Lok™ More secure than ordinary padlocks |
0.4 | $22.00 |
LOAD CAPACITY
Your Draftmaster’s loading limit is whichever is reached first - A, B, or C.
A) 100 lbs (45.5 kg) per Sxx-TA series specialty rail
50 lbs (22.75 kg) per classic Sxx series and STT specialty rails
100 lbs (45.5 kg) per single bike for both classic and thru axle fork mounts
B) 200 lbs (91 kg) all bikes combined
C) ½ your receiver’s tongue load limit as rated for your vehicle
including the weight of the Draftmaster and bikes
TWO WAYS TO ORDER A DRAFTMASTER
Both ordering methods are equivalent. Same packaging. Same price. Just two ways to order the same great product!
Bundled Systems: Our HR- (Hitch Rack) bundled system codes offer simplified & convenient “one item code” ordering of our popular configurations. All bundled systems have standardized configurations without substitutions. There is a good chance that one of our bundled systems meets your needs. If not, reviewing them is still a great place to start as you decide what configuration works best for you.
Individual Modules: Or “al a carte” as we sometimes call it. Because listing a bundled system HR- code for every possible configuration is not practical. Choose the specific combination of modules that meets your needs.
Custom configuration: No, not a third way. We just want to point out that the offerings below are only a sample of what the Draftmaster can do. If you don’t see what you need, talk to us. We can probably do it!
BUNDLED SYSTEMS
All bundled systems include a standard length 2.00" receiver Interconnect (Int200). Systems needing a 1.25" or extra long 2.00" Interconnect, or for configurations not listed, please order individual modules. THERE IS NO PRICE DIFFERENTIAL WHEN ORDERING BUNDLED SYSTEMS vs. INDIVIDUAL MODULES. |
|---|
| Item Code | Modules Included | Application | Approximate Installed Wt (lbs) |
MSRP | Notes |
|---|---|---|---|---|---|
| HR-1tTrike | INT200 CAA-0001-4309 (1) STT-G2 |
1 tadpole trike | 46.3 | $1,592.00 | |
| HR-2tTrike | INT200 CAA-0002-7656 (2) STT-G2 |
2 tadpole trikes | 62.7 | $2,435.00 | |
| HR-1dTrike | INT200 CAA-0010-0943 (1) S63 |
1 delta trike | 46.2 | $1,592.00 | 5 |
| HR-1dTrike+1tTrike | INT200 CAA-0011-5656 (1) S63 + (1) STT-G2 |
1 delta trike + 1 tadpole trike | 61.6 | $2,378.00 | 5 |
| HR-2dTrike | INT200 CAA-0020-5676 (2) S63 |
2 delta trikes | 62.6 | $2,435.00 | 5 |
| HR-1S76 | INT200 CAA-0100-0909 (1) S76 |
1 tandem | 45.3 | $1,487.00 | 6 |
| HR-2S76 | INT200 CAA-0200-3030 (2) S76 |
2 tandems | 60.6 | $2,171.00 | 6 |
| HR-3S76 | INT200 CAA-0300-4343 (3) S76 |
3 tandems | 75.1 | $2,803.00 | 6 |
| HR-1+1tTrike | INT200 CAA-1001-4343 (1) STT-G2 |
1 standard bicycle + 1 tadpole trike | 48.9 | $1,727.00 | 6 |
| HR-1+1S76 | INT200 CAA-1100-3030 (1) S76 |
1 standard bicycle + 1 tandem | 48.3 | $1,656.00 | 6 |
| HR-2 | INT200 CAA-2000-3030 |
2 standard bicycles | 36.0 | $1,141.00 | |
| HR-2+1tTrike | INT200 CAA-2001-5656 (1) STT-G2 |
2 standard bicycles + 1 tadpole trike | 50.9 | $1,909.00 | |
| HR-2+1dTrike | INT200 CAA-2010-5656 (1) S63 |
2 standard bicycles + 1 delta trike | 50.9 | $1,909.00 | 5 |
| HR-2+1S76 | INT200 CAA-2100-3030 (1) S76 |
2 standard bicycles + 1 tandem * MOST POPULAR * |
49.1 | $1,749.00 | 6 |
| HR-2+1S76 wide | INT200 CAA-2100-4343 (1) S76 |
2 standard bicycles + 1 tandem | 50.4 | $1,773.00 | 6 |
| HR-2+2S76 | INT200 CAA-2200-5656 (2) S76 |
2 standard bicycles + 2 tandems | 64.8 | $2,470.00 | |
| HR-3 | INT200 CAA-3000-4343 |
3 standard bicycles | 38.1 | $1,258.00 | |
| HR-4 | INT200 CAA-4000-4343 |
4 standard bicycles | 39.0 | $1,351.00 | |
| HR-4+1S76 | INT200 CAA-4100-5656 (1) S76 |
4 standard bicycles + 1 tandem | 53.3 | $2,048.00 | 6 |
| HR-5 | INT200 CAA-5000-5656 |
5 standard bicycles | 41.0 | $1,533.00 |
Notes:
1.25” receivers, especially Class I, are limited in carrying capacity. Atoc recommends that the combined weight of the Draftmaster rack and bikes not exceed 50% of your receiver's tongue load capacity
Supplied as standard equipment with all Bundled Systems.
Extends Draftmaster back an additional 7.5" to clear rear-mounted spare tire or to give additional vehicle clearance.
Measure the wheelbase of your cycle accurately to order the proper length Specialty Rail.
S63 supplied as standard equipment unless requested otherwise.
S76 supplied as standard equipment unless requested otherwise.
INDIVIDUAL MODULES
INTERCONNECT The swing-away parallelogram mechanism. It plugs into your receiver and supports the Cross Arm Assembly. |
|---|
| Item Code | Application | Approximate Installed Wt (lbs) |
MSRP | Notes |
|---|---|---|---|---|
| Int125 | with connection for 1.25" Class I and II receivers | 27.8 | $575.00 | 1 |
| Int200 | with connection for 2.00" Class II+, III, and IV receivers | 26.5 | $575.00 | 2 |
| Int200XL | with extra long (+7.5") connection for 2.00" Class II+, III, and IV receivers | 29.3 | $610.00 | 3 |
CROSS ARM ASSEMBLY By using cross arms of various widths and changing the number and position of fork mounts/wheel trays we can configure a Draftmaster to your specific needs. See the Quick Reference Guide for an explanation of CAA codes. OTHER CONFIGURATIONS ARE AVAILABLE - JUST ASK US. |
|---|
| Item Code | Application | Approximate Installed Wt (lbs) |
MSRP | Notes |
|---|---|---|---|---|
| CAA-0001-4309 | 1 tadpole trike | 9.1 | $548.00 | |
| CAA-0002-7656 | 2 tadpole trikes | 14.8 | $922.00 | |
| CAA-0010-0943 | 1 delta trike | 9.1 | $548.00 | |
| CAA-0011-5656 | 1 delta trike + 1 tadpole trike | 13.7 | $865.00 | |
| CAA-0020-5676 | 2 delta trikes | 14.8 | $922.00 | |
| CAA-0100-0909 | 1 tandem | 6.8 | $413.00 | |
| CAA-0200-3030 | 2 tandems | 10.1 | $598.00 | |
| CAA-0300-4343 | 3 tandems | 12.6 | $731.00 | |
| CAA-1001-4343 | 1 standard bicycle + 1 tadpole trike | 11.7 | $683.00 | |
| CAA-1100-3030 | 1 standard bicycle + 1 tandem | 9.8 | $582.00 | |
| CAA-2000-3030 | 2 standard bicycles | 9.5 | $566.00 | |
| CAA-2001-5656 | 2 standard bicycles + 1 tadpole trike | 13.7 | $865.00 | |
| CAA-2010-5656 | 2 standard bicycles + 1 delta trike | 13.7 | $865.00 | |
| CAA-2100-3030 | 2 standard bicycles + 1 tandem * MOST POPULAR * |
10.6 | $675.00 | |
| CAA-2100-4343 | 2 standard bicycles + 1 tandem | 12.0 | $699.00 | |
| CAA-2200-5656 | 2 standard bicycles + 2 tandems | 14.3 | $897.00 | |
| CAA-3000-4343 | 3 standard bicycles | 11.7 | $683.00 | |
| CAA-4000-4343 | 4 standard bicycles | 12.5 | $776.00 | |
| CAA-4100-5656 | 4 standard bicycles + 1 tandem | 14.9 | $974.00 | |
| CAA-5000-5656 | 5 standard bicycles | 14.6 | $958.00 |
SPECIALTY RAILS Add-on modules to carry bikes with wheelbases longer than 48 inches (tandems, cargo bikes, etc.) and other specialty applications such as trikes. Quick connect mount to the Cross Arm Assembly. |
|---|
| Item Code | Application | Approximate Installed Wt (lbs) |
MSRP | Notes |
|---|---|---|---|---|
| S63 | Cargo bikes, delta trikes, and other bikes with wheelbases up to 63" Also fits all ElliptiGO models |
10.7 | $469.00 | 4 |
| S63-TA(size) | Thru axle compatible & heavy duty version of the S63 Available in thru axle sizes 12x100, 12x110, 15x100, and 15x110 Classic 9x100 Quick Release version also available (add $20) |
11.2 | $569.00 | 4 |
| S76 | Tandems, cargo bikes, LWB recumbents, and delta trikes with wheelbases up to 76" | 12.0 | $499.00 | 4 |
| S76-TA(size) | Thru axle compatible & heavy duty version of the S76 Available in thru axle sizes 12x100, 12x110, 15x100, and 15x110 Classic 9x100 Quick Release version also available (add $20) |
12.5 | $599.00 | 4 |
| S84 | Tandems, LWB recumbents, and other extra long bikes with wheelbases up to 84" | 12.9 | $529.00 | 4 |
| S84-TA(size) | Thru axle compatible & heavy duty version of the S84 Available in thru axle sizes 12x100, 12x110, 15x100, and 15x110 Classic 9x100 Quick Release version also available (add $20) |
13.4 | $629.00 | 4 |
ACCESSORIES & -OE FACTORY SUBSTITUTIONS
| Item Code | Description | MSRP | Notes |
|---|---|---|---|
| TL | Topper Lok™ security skewer Lockable, long-throw cam, rust proof Fits all 9mm fork mounts with a removable skewer Uses an ordinary padlock or ML605 below |
$79.00 | |
| TL-OE | Upgrade any Draftmaster or Topper Rack to a Topper Lok™ Original Equipment factory substitution for standard skewer |
$73.00 | |
| ML605 | This hard-to-find padlock works great with our Topper Lok™ More secure than ordinary padlocks. |
$22.00 | |
| FMA-TA(size)R-OE | Upgrade a classic QR style Fork Mount Assembly to thru axle style Thru axle axis ROTATES to facilitate bike loading Available in thru axle sizes 12x100, 12x110, 15x100, and 15x110 Classic 9x100 Quick Release version also available (add $20) Original Equipment factory substitution for classic FMA |
$100.00 | |
| FMA-TA(size)S-OE | Upgrade a classic QR style Fork Mount Assembly to thru axle style Thru axle axis does NOT rotate Available in thru axle sizes 12x100, 12x110, 15x100, and 15x110 Classic 9x100 Quick Release version also available (add $20) Original Equipment factory substitution for classic FMA |
$70.00 | |
| WTA300 | Wheel Tray Assembly for Draftmaster Cross Arms 300 mm long. Fits tires up to 2.5 inches (63 mm) wide (standard WTA tray is 200 mm long) |
$48.00 | |
| WTA300-OE | Same as WTA300 but supplied as an Original Equipment factory substitution for standard WTA. |
$6.00 | |
| WTA200F | Fat Wheel Tray Assembly for Draftmaster Cross Arms 200 mm long. For tires wider than 2.5 inches (63 mm) actual width Includes extra long wheel strap |
$68.00 | |
| WTA200F-OE | Same as WTA200F but supplied as an Original Equipment factory substitution for standard WTA. |
$25.00 | |
| WTA300F | Fat Wheel Tray Assembly for Draftmaster Cross Arms 300 mm long. For tires wider than 2.5 inches (63 mm) actual width Includes extra long wheel strap |
$78.00 | |
| WTA300F-OE | Same as WTA300F but supplied as an Original Equipment factory substitution for standard WTA. |
$35.00 | |
| WTAK | Wheel Tray Adapter Kit Temporarily converts a Specialty Rail position to a standard bicycle position |
$66.00 | |
| SFM | Secondary Fork Mount Adds another fork mount to an S or S-TA Specialty Rail Positions anywhere along the Rail |
$99.00 | |
| SHB125 SHB200 |
Security Hitch Bolt for receiver connection (pending redesign) | tbd | |
| FWC | Front Wheel Carrier Holds up to 4 classic quick release wheels (pending redesign to accept thru axle wheels) |
tbd |
OTHER STUFF
| LITE BEAMS™ | Put your light where you want it |
|---|
| Lo Beam | Replaces adjustable nut on quick release skewer. Self-indexing, light never needs to be re-aimed. | $35.00 |
|---|---|---|
| Mid Beam | Attaches to any convenient 5mm mounting boss - frame, fork, rack, etc. | $30.00 |
| CYCLE ART DECALS |
|---|
| Great for windows, bumpers, etc. White weather-proof vinyl. Background peels away - only the graphic stays. Minimum order 2 decals. Order with other product or postal order only. |
| DCL-bent | Recumbent rider | $3.00 |
|---|---|---|
| DCL-trike | Tadpole trike rider | $3.00 |
| DCL-sngl | Traditional single rider | $3.00 |
| DCL-tndm | Tandem riders | $3.00 |
